Product Category
As a core precision stamping category, Compound Die integrates multiple operations (blanking, punching, drawing, etc.) in one press cycle. It boasts high accuracy (±0.02~±0.04mm), long service life (over 500,000 cycles), and suits auto, home appliance, and electronic part mass production. Below is a detailed intro to its products, technical traits, and advantages.
Feature Box
One-Cycle Multi-Process Integration
Covers blanking, punching, drawing, and bending—finishes 2-4 stamping steps in one press run, boosting efficiency by over 300% vs single-process dies.
High-Precision Control
Maintains coaxial error of ±0.02~±0.04mm, meeting strict precision demands for automotive and medical precision components.
Long-Service-Life Design
Adopts high-strength steel die holders and ball-bearing guide frames, supporting over 500,000 cycles without frequent maintenance.
Strong Adaptability
Comes with spherical floating shanks (fits old stamping machines) and elastic stripping devices, ensuring workpiece flatness while compatible with diverse equipment.
Application
With one-cycle multi-process integration, ±0.02~±0.04mm precision, and strong material/equipment adaptability, our Compound Die meets stamping needs for mass production and consistent quality. It’s widely used in three core sectors—automotive components, home appliance hardware, electronic precision parts—solving pain points like low efficiency or poor precision. Here’s its application in each field:
Automotive Components Manufacturing
Ideal for producing high-precision auto parts that require multi-step stamping, such as front fender shaping-flanging-punching and seal cover blanking-drawing. Its ±0.02~±0.04mm coaxial accuracy meets the strict precision standards of automotive industry, while one-cycle multi-process integration supports mass production of over 500,000 units, effectively reducing production time and costs.
Home Appliance Hardware Production
Widely used in one-step forming of home appliance hardware like air conditioner top covers and lamp holder stretching-flanging. Compatible with materials including carbon steel, aluminum and copper, it leverages elastic stripping devices to ensure workpiece flatness. Compared with progressive dies, it cuts costs by 20% for medium and large batch orders, fitting the cost-sensitive needs of home appliance manufacturing.
Electronic Precision Parts Processing
Suitable for stamping small-sized, high-precision electronic components such as copper/stainless steel connector terminals. With coaxial error control up to ±0.03mm, it meets the micro-precision requirements of electronic parts. The ball-bearing guide frame and high-strength steel die holder enable over 500,000 cycles of stable operation, avoiding frequent die replacement and ensuring continuous production of electronic components.
Product Advantages
Efficiency Boost via One-Cycle Multi-Process
Unlike single-process dies that require multiple press runs, this Compound Die integrates 2-4 key operations (blanking, punching, drawing, bending) into one cycle—directly improving production efficiency by over 300%. For mass orders (500,000+ units), it also reduces production time by half compared to traditional dies, perfectly matching the speed needs of large-batch manufacturing.
High Precision Meeting Strict Industry Standards
With coaxial error controlled at ±0.02~±0.04mm, it outperforms most competing dies (common error: ±0.05mm) and meets the precision requirements of high-end fields like automotive parts (e.g., front fender processing) and medical components. Even for small electronic parts (e.g., connector terminals), it maintains stable precision to ensure product consistency.
Long Service Life Reducing Maintenance Costs
Adopting high-strength steel die holders (instead of fragile cast iron) and ball-bearing guide frames, the die’s service life reaches over 500,000 cycles—nearly 70% longer than ordinary compound dies (300,000 cycles). Its simplified 4-process max structure also cuts maintenance time by 50% vs complex 5-process competitors, lowering downtime costs for enterprises.
Strong Adaptability to Equipment & Materials
Equipped with a spherical floating shank, it compensates for errors of old stamping machines, avoiding the need for costly equipment upgrades (a common pain point with competitors). It also supports diverse materials (carbon steel, aluminum, copper, stainless steel) and uses elastic stripping devices to ensure workpiece flatness—solving material compatibility and quality stability issues for multi-scenario production.
